1 HP Elite TENV Stainless Bremas Wired Motor with Base

The 1 HP Elite TENV Stainless Bremas Wired Motor with Base is a single-phase, dual-voltage boat lift motor.. The welded base of the motor is compatible with standard mounting patterns found on flat-plate gear plates, which are commonly used in boat hoists to lift and lower boats. Made from stainless steel housing and features aluminum end plates that resist corrosion and rust. The heavy marine-grade gasket on the stainless steel capacitor housing helps keep water and dust out. Easy to wire with standard yellow T-Wires and works with any known drum switch or boat lift remote.

This motor is engineered to seamlessly integrate with a range of flat-plate hoists from reputable brands like Boat Hoist USA, ACE Labs, American Power Hoist, AMS, and Hefty Hoist. It comes with detailed wiring instructions compatible with Breams and Salzer drum switches, ensuring smooth installation and operation. Additionally, it is fully compatible with remote controls from GEM, Galaxy, TEC, and Elite for convenient and efficient boat lift operation. Furthermore, this motor is equivalent to the Leeson boat hoist motor #6439191252, providing comparable performance and reliability.

You can choose between a Bremas maintained (lock-on) or momentary (spring-loaded) boat lift switch. Both switches are connected with 14/5 SJTW control cable, with the in-line GFCI located 4 1/2 inches away from the plug. The type of plug and GFCI wired to the wiring harness depends on your motor voltage selection.

The motor has a power rating of 1 horsepower (HP) and can run on either 115 volts or 230 volts. When operating at 115 volts, it draws 15.6 amps, and at 230 volts, it draws 7.8 amps. It spins at a speed of 1725 revolutions per minute (RPM) with a frequency of 60 Hz. It belongs to frame 56c and has a service factor of 1.15. The motor can handle up to 17.5 amps at 115 volts or 8.75 amps at 230 volts. It can operate in an ambient temperature of up to 40°C for a maximum of 15 minutes. The housing is Totally Enclosed Non-Ventilated (TENV) with a code of H. It has insulation class F and is UL recognized with a C-UL-US stamp.
