1 HP Elite TENV Stainless Electric Motor With Base

The 1 HP Elite TENV Stainless Electric Motor With Base is a single-phase, dual-voltage boat lift motor. The welded base of the motor is compatible with standard mounting patterns found on flat-plate gear plates, which are commonly used in boat hoists to lift and lower boats.  The Elite Motor has a marine grade stainless steel housing and features aluminum end plates that resist corrosion and rust. The heavy marine-grade gasket on the stainless steel capacitor housing helps keep water and dust out. Easy to wire with standard yellow T-Wires and works with any known drum switch or boat lift remote.

This motor will work on all flat-plate hoist brands including:  Boat Hoist USA, ACE Labs, American Power Hoist, AMS, and Hefty Hoist. It comes with detailed wiring instructions for wiring too Breams and Salzer drum switches, ensuring easy installation.  Additionally, it is fully compatible with remote controls from GEM, Galaxy, TEC, and Elite for convenient and efficient boat lift operation.  This motor is equivalent to the Leeson boat hoist motor #6439191252.

The motor has a power rating of 1 horsepower (HP) and can run on either 115 volts or 230 volts. When operating at 115 volts, it draws 15.6 amps, and at 230 volts, it draws 7.8 amps. It spins at a speed of 1725 revolutions per minute (RPM) with a frequency of 60 Hz.  It is a 56 frame mount and has a service factor of 1.15. . It can operate at an ambient temperature of up to 40°C for a maximum of 15 minutes. The housing is Totally Enclosed Non-Ventilated (TENV). It has insulation class F and is UL-recognized with a C-UL-US stamp.
