3 Ton Eye Hoist Hook
$ 19.19
SKU: 75645
UPC: 091037756459
Special Order
Stock Policy
Shipping Policy
Return Policy
3 Ton Eye Hoist Hook
The 3 Ton Eye Hoist Hook is forged, quenched & tempered. Proof Load is 2 times the Working Load Limit. Ultimate Load is 5 times the Working Load Limit. 320C-Carbon Steel. Features a spring-loaded 1.34 in. latch. 3-ton safe working limit. 1.56 in. eye diameter. 5.78 in. from top of the eye to bottom of hook opening. 1.38 in. between latch swing and bottom of hook opening. Weighs 3.66 lbs. 5 in. L x 3/4 in. W x 7 13/16 in. H overall dimensions.
Stamped rating ensures the hook meets all safety standards and regulations.
Specifications
| Size: | 2 ton | 3 ton |
| Dimensions: | 4 in. L x 3/4 in. W x 6 3/8 in. H | 5 in. L x 3/4 in. W x 7 13/16 in. H |
| B Dimensions: | 1.25 in. | 1.56 in. |
| E Dimensions: | 1.12 in. | 1.34 in. |
| R Dimensions: | 4.69 in. | 5.78 in. |
| T Dimensions: | 1.19 in. | 1.38 in. |
| Weight: | 1.76 lbs. | 3.66 lbs. |
| Material: | 320C – carbon steel | 320C – carbon steel |
| Safe Working Load: | 2-ton | 3-ton |
