6 in. x 25 ft. Aluminum Channel
$ 471.44
- Made from 6061-T6 US aluminum
- 6 in. x 2 1/2 in. x .17/.29 x 25 ft.
- 2.834 wt/in ft.
- Raw, uncut aluminum channel
- Local Pickup Only (Longview, TX)
SKU: 83031AL
In stock
Special Order
Stock Policy
Shipping Policy
Return Policy
6 in. x 25 ft. Aluminum Channel
The 6 in. x 25 ft. Aluminum Channel measures 6 in. x 2 1/2 in. x .17/.29 x 25 ft. Made from 6061-T6 US aluminum. 2.834 wt/in ft. Raw, uncut aluminum channel.
DUE TO SHIPPING RESTRAINTS, THIS PRODUCT IS ONLY AVAILABLE FOR PICKUP AT OUR LONGVIEW, TX FACILITY.
6061-T6 Marine-Grade US Aluminum
6061-T6 is an all-around popular grade of aluminum. Commonly used in marine applications. Very good corrosion resistance and is precipitation hardened. These grades, for the most part, have additional chromium and manganese to help protect them from corrosive marine conditions. The aluminum channel falls into this category.
T6 temper 6061 US Aluminum
T6 temper 6061 has an ultimate tensile strength of at least 290 MPa (42,000 psi) and yield strength of at least 240 MPa (35,000 psi). More typical values are 310 MPa (45 ksi) and 270 MPa (39 ksi), respectively. In thicknesses of 6.35 mm (0.250 in) or less, it has elongation of 8% or more; in thicker sections, it has elongation of 10%. T651 temper has similar mechanical properties. The typical value for thermal conductivity for 6061-T6 at 25 °C (77 °F) is around 152 W/m K. A material data sheet defines the fatigue limit under cyclic load as 97 MPa (14,000 psi) for 500,000,000 completely reversed cycles using a standard RR Moore test machine and specimen.”
