8 in. Aluminum Structural Beam

$310.22 - $716.92
Make Your Selection:
×

Shipping

Boat Hoist USA has partnered with UPS to offer Ground, Next Day Air, 2nd Day Air, and 3 Day Select services to our customers. In order to ship with these methods, the order must meet UPS's requirements.

Freight

Your order will be shipped via the most cost-effective method possible. All shipping and handling charges are the responsibility of the customer. Additionally, they are responsible for any delivery issues that may hinder delivery. In such cases, extra fees can apply, such as residential delivery fees.

Click the button below to learn more about our ordering and shipping policies.

Our Shipping Partners shipping modal logos

Qty.




8 in. Aluminum Structural Beam

The 8 in. Aluminum Structural Beam is an extruded aluminum I-beam. Made from marine-grade, extruded 6o61-T6 US aluminum. No weld construction. The sheave housings include the cradle beam mounting fasteners. Measures 12 ft. 6 in. L or 25 ft. L x 8 in. web x 5 in. flange. .250 in. web thickness. .410 in. flange thickness. 6.307 lbs. per linear ft.

Drilling into the aluminum structural beam compromises the integrity of the aluminum structural beam.
Beams cannot be shipped UPS Ground. The beams are secured to a pallet and ships via Freight. The end-user is responsible for unloading. Freight companies will not unload or drop off your load if you are not present. It is the purchaser’s responsibility to arrange a delivery date with the freight company. Shipping to a business address with a forklift is highly recommended by BH-USA.
25 ft. beams are Local Pickup Only from our Longview, TX Facility.
Specifications

General Specifications

Material: Aluminum Type: 6061-T6 US
Style: Marine-grade extruded Beam Type: Structural
Web Size (A): 8 in. Flange Size (B): 5 in.
Web Thickness (C): .250 in. Flange Thickness: .410 in.
Beam Wt./Lin Ft.: 6.307 lbs. (per ft.) Ships: Freight
Drilling into the aluminum structural beam compromises the integrity of the aluminum structural beam.
Beams cannot be shipped UPS Ground. The beams are secured to a pallet and ships via Freight. The end-user is responsible for unloading. Freight companies will not unload or drop off your load if you are not present. It is the purchaser’s responsibility to arrange a delivery date with the freight company. Shipping to a business address with a forklift is highly recommended by BH-USA.
