Aluminum Pile Mount A-Drive Mount Bracket
Aluminum Pile Mount A-Drive Mount Bracket
Aluminum Pile Mount A-Drive Mount Bracket
Aluminum Pile Mount A-Drive Mount Bracket
Aluminum Pile Mount A-Drive Mount Bracket
Aluminum Pile Mount A-Drive Mount Bracket

Aluminum Pile Mount A-Drive Mount Bracket

$ 81.26
  • No weld, all extruded design
  • Made from 6061-T6 US aluminum
  • Mounts directly to aluminum top beam and A-Drive boat hoist
  • Fits A-Drive mounting pattern
  • Works will all aluminum BH-USA pile mount boat lifts
SKU: 97186
UPC: 602573971864

In stock

in stock

Free Shipping
×

Free Shipping

BH-USA offers free shipping for retail customers on select items. Products eligible for free shipping will be shipped via UPS Ground. We offer expedited services for those individuals that require a more time-sensitive delivery time. If you add any items that are not free shipping, the cart will calculate and display a shipping price based on ONLY the items that are not free shipping. Whenever free shipping is available, it will appear above the "Add to Cart" button on the product page.

×

Shipping

BH-USA has partnered with UPS to offer Ground, Next Day Air, 2nd Day Air, and 3 Day Select services to our customers. In order to ship with these methods, the order must meet UPS's requirements.

Freight

Your order will be shipped via the most cost-effective method possible. All shipping and handling charges are the responsibility of the customer. Additionally, they are responsible for any delivery issues that may hinder delivery. In such cases, extra fees can apply, such as residential delivery fees.

Click the button below to learn more about our ordering and shipping policies.

Our Shipping Partners shipping modal logos

Qty.



Aluminum Pile Mount A-Drive Mount Bracket

The Aluminum Pile Mount A-Drive Mount Bracket mounts an a-drive hoist to the top beam of an aluminum pile mount boat lift. Made from extruded 6061-T6 US aluminum. Measures 9 in. L x 3.465 in. W x 6.772 in. H. .390 in. thickness. (4) .344 in. standard A-Drive mounting holes with 2.75 in. drive pipe opening. (2) 1.375 in. mounting slots.

It fits all BH-USA A-Drive hoists, Coastal Series aluminum pile mount boat lifts, and aluminum channel construction top beams. Lift rated from 6,000 lbs. – 24,000 lbs. Requires (6) 1/2 in. x 2 in. stainless steel hex head bolts, (6) 1/2 in. stainless steel washers, and (6) 1/2 in. stainless steel nuts.
