Attabox Enclosure for Elite Remotes
Specifications
Color | Gray | Cover Type | Opaque |
Latch Material | Polycarbonate with UV Inhibitors | Mounting Type | Wall Mount |
Material | Polycarbonate | Back Panel Screw Size | #10-32 x 3/8 |
Back Panel Recommended Torque | 16-20 in-lbs. | Back Panel Screw Material | Zinc Plated |
Cover Screw Size | #10-32 x 5/8 | Cover Screw Recommended Torque | 20-24 in-lbs. |
Cover Screw Material | 304 SS | Mounting Foot Screw Size | 1/4-20 x 1/2 |
Mounting Foot Screw Recommended Torque | 10-14 in-lbs. | Installation Mounting Torque | 25-30 in-lbs. Max |
Metal Inserts | Brass | Hinge Material | Integral Polycarbonate |
Gasket Material | Poured In Place (PIP) Polyurethane Seamless | Country of Origin | USA |
Outer Dimensions | 8.5 in. W x 9.5 in. H x 6 in. D | Inner Dimensions | 8 in. W x 6 in. H x 4 in. D |
Useable Depth (in) | 4.6 | Useable Depth (mm) | 116.0 |
Standards | NEMA 250; UL 50; UL 50e; UL508A cULus Listed File #E319779 | Type | 1; 3R; 4; 4X; 6; 6P; 12 |
IEC 60529 | IP66; IP68 | IEC cULus Listed File | #E362920 |
Temperature Range (°F) | -40°F to +248°F | Temperature Range (°C) | -40°C to +120°C |
Flammability Rating | UL94-5VA | Outdoor Exposure | UL746c (f1) Rated |
CE | Certified |
