E-Drive Hoist Hanger

SKU: 62537 UPC: 658580625375

$320.79

Only 13 left in stock

in stock. only 13 left!

Free Shipping
×

Free Shipping

Boat Hoist USA offers free shipping for retail customers on select items. Products eligible for free shipping will be shipped via UPS Ground. We offer expedited services for those individuals that require a more time-sensitive delivery time. If you add any items that are not free shipping, the cart will calculate and display a shipping price based on ONLY the items that are not free shipping. Whenever free shipping is available, it will appear above the "Add to Cart" button on the product page.

Qty.



In Stock

Have questions about this product? Contact us.

E-Drive Hoist Hanger

The E-Drive Hoist Hanger is a dual pipe support that you mount a BH-USA E-Drive to the end of. The drive-pipe collars fit 2 3/8 in. OD (2 in. ID) drive pipes that mount directly into the gear of the e-drive. Each drive pipe sleeve has 1/4 in. grease fitting pre-installed and offset for easier greasing. The E-Drive mounts to a welded bar with (2) 0.63 in. (5/8 in.) holes. The 1/4 in. thick flat-plates have a hole lazer cut that fits 2 3/8 in. OD (2 in. ID). There are (4) 1.25 in. x 0.75 in. slots of 0.25 in. flat-plate to mount the drive pipe overhead. Made from 6061-T6 US aluminum.

E-Drive Hoist Hanger

Product Details

Product Overview
  • Fits new BH-USA E-Drive
  • Dual drive pipe supports with hoist hanger bar
  • Made from 6061-T6 US aluminum
  • Fits 2 3/8 in. OD (2 in. ID) drive pipes
  • Offset grease zerks for greasing drive pipe
Specifications

General Specifications

Material: Aluminum Designation: E-Drive
Weight: 15.85 lbs. Grease Fittings: 2
Length: 28.5 in. Grease Fitting Size: 0.25 in.
Width: 9.25 in. Sleeves: 2
Height: 8.5 in. Sleeve Width: 2.9375 in.
Sleeve Fits: 2 3/8 in. OD (2 in. ID) Sleeve Thickness: 0.25 in.
Drive Mount Holes: 2 Drive Mount Hole Size: 0.63 in.
Mounting Slots: 4 Mounting Slot Size: 1.25 in. x 0.75 in.
