Galvanized Boat Cradle Guidepost Stanchion Kit
$ 344.25
SKU: 70233
UPC: 816146022406
In stock
Special Order
Stock Policy
Shipping Policy
Return Policy
Galvanized Boat Cradle Guidepost Stanchion Kit
The Galvanized Boat Cradle Guidepost Stanchion Kit fits 4 in. & 5 in. wide galvanized cradle beams. Made from hot-dipped galvanized steel. Easy to install on preexisting boat cradle beams. Allows 2 in. ID PVC pipe to slide over the stanchion. Stanchions measure 24 in. x 1 1/2 in. diameter.
Installation
The fastener bolts go through the stanchion mounting holes through the back plate and are secured with a lock washer and nut. The cradle beam being in the middle allows the stanchion to “clamp” tight onto the cradle beam. Then use an optional guidepost to slide on top of the stanchion.
Includes all galvanized mounting fasteners.
Optional Capped White PVC Guidepost and Guidepost Bumpers are sold separately.
Specifications
| Material: | Steel | Finished: | Hot-dipped galvanized |
| Stanchion Size: | 24 in. x 1.5 in. diameter | Back-Up Plate Size: | 10 in. x 2 in. (each flange) |
| Mounting Bolt Size: | 1/2 in. | Accepts: | 2 in. ID PVC pipe to slide over |
| Fits Flange Size: | 4 in. – 5 in. cradle beams | Close Hole Spacing: | 1 1/2 in. |
| Wide Hole Spacing: | 6 3/8 in. | Guideposts / Bumpers: | Not Included |
