Single Pillow Block Hanger Bracket
Single Pillow Block Hanger Bracket
The Single Pillow Block Hanger Bracket mounts directly to wood beams or wooden joists. Designed for a standard pillow block to mount to the plate. The pillow block helps support the weight of the drive pipe. Made from 1/4 in. hot-dipped galvanized steel. Feature (2) 3/4 in. pillow block mounting holes. 7 1/4 in. center-to-center on the plate. Built with (2) 1/2 in. wood beam mounting holes. Measuring 4 in. center-to-center.
Wood beam mounting fasteners not included.
Center mount only.
Specifications
| Dimensions: | 9 1/2 in. L x 3 in. W x 12 5/16 in. H |
| Weight: | 8.85 lbs. |
| Material: | Steel |
| Finish: | Hot-dipped Galvanized |
| Wood Beam Mounting Holes: | 2 |
| Mounting Hole Size: | 1/2 in. |
| Hole Location: | Center of Flat Plate |
| Distance Between Holes: | 4 in. (Center-to-Center) |
| Plate Edge to Mounting Hole: | 1 1/2 in. |
| Hole to Block Plate Distance: | 6 1/4 in. |
| Pillow Block Mounting Holes: | 2 |
| Mounting Hole Size: | 3/4 in. |
| Hole Location: | Center of Flat Plate |
| Distances Between Holes: | 7 1/4 in. (Center-to-Center) |
| Plate Edge to Mounting Hole: | 1 3/16 in. |
Use with BH-USA pillow block hangers, recommended for center mount only. Rating is only based on proper installation with weight on the flange as the image shown. Do not attempt to hang and put a direct load on the block. Always use the BH-USA Overhead Lift Guide when designing your overhead lift. BH-USA does not recommend overhead lifts for boats weighing more than 12,000 lbs.
Recommended for the center mount. Must use full-length pipe connecting two hangers. Never use a short piece of pipe. Always use the BH-USA overhead lift guide when designing your overhead lift. BH-USA does not recommend overhead lifts for boats weighing more than 12,000 lbs.
