Single Thread Steel Worm
Single Thread Steel Worm
Single Thread Steel Worm
Single Thread Steel Worm
Single Thread Steel Worm

Single Thread Steel Worm

$ 84.80
  • Used on BH-USA Advanced series boat hoists
  • Made from hardened, polished steel
  • Measures 2 in. w x 1 3/4 in. diameter
  • Features a .754 in. bore
  • Right hand threaded worm
SKU: 75610
UPC: 091037756107

Only 5 left in stock

in stock. only 5 left!

Free Shipping
×

Free Shipping

BH-USA offers free shipping for retail customers on select items. Products eligible for free shipping will be shipped via UPS Ground. We offer expedited services for those individuals that require a more time-sensitive delivery time. If you add any items that are not free shipping, the cart will calculate and display a shipping price based on ONLY the items that are not free shipping. Whenever free shipping is available, it will appear above the "Add to Cart" button on the product page.

×

Shipping

BH-USA has partnered with UPS to offer Ground, Next Day Air, 2nd Day Air, and 3 Day Select services to our customers. In order to ship with these methods, the order must meet UPS's requirements.

Freight

Your order will be shipped via the most cost-effective method possible. All shipping and handling charges are the responsibility of the customer. Additionally, they are responsible for any delivery issues that may hinder delivery. In such cases, extra fees can apply, such as residential delivery fees.

Click the button below to learn more about our ordering and shipping policies.

Our Shipping Partners shipping modal logos

Qty.



Single Thread Steel Worm

The Single Thread Steel Worm is a right-hand threaded worm. Works will all BH-USA flat-plate hoists and gear plates with a 96-tooth worm gear (flat-plate boat hoists). Made from polished, hardened steel. Features a .754 in. bore. Match steel worm with a bronze 96-tooth worm gear. Featured on the BH-USA Advanced Series of flat-plate boat hoists. Single thread means it rotates one way. The teeth of the bronze 96-tooth worm gear fit into the grooves of the worm. The motor turns the drive belt and pulleys that turn the driveshaft and the worm.

Never use steel worm on a cast iron worm gear.
