12K Aluminum Six Post Top Beam Kit

The 12K Aluminum Six Post Top Beam Kit is used on the 20,000 lb. & 24,000 lb. six post pile mount lift. (2) top beams make it able to handle 20K-24K pounds. Made from marine-grade 6061-T6 US aluminum. Features a no-weld design. Includes all stainless steel mounting fasteners. The bronze bearings have 1/4 in. easy-to-reach grease fittings. The top beam is drilled out for a flat-plate hoist to be installed onto a flat-plate hoist. Made of sch. 40 galvanized steel. Measures 14 ft. 6 in. with a 1.5 in. ID. Includes one-direction side-mounted (boat lift style) cable winders.

Boat Lift Motor, Switch, or boat cradle not included.

Kit Includes:

(1) – 15 ft. six post piling top beam w/ 1/2 in. stainless steel fasteners
(1) – A-Drive mount bracket
(2) – 1 1/2 in. ID single directional boat lift style cable winders
(1) – 14 ft. 6 in. x 1 1/2 in. OD galvanized drive pipe
(1) – 40:90 A-Drive 7k worm gear reducer
(2) – 33 ft. x 3/8 in. 7 x 19 aircraft cable w/ 1/4 in. malleable clips
(1) – 1.5 in. 7k A-Drive shaft
(1) – 4 post 24k switch place
(6) – 1/2 in. x 2 in. stainless steel hex head bolts (13 thread)
(1) – 1/2 in. x 2 1/2 in. stainless steel hex head bolt w/ 1/2 in. nylok nut
(1) – Aluminum cradle axle bolt fastener kit (includes 4 axle bolts, washers, & nuts)
(4) – 4 in. aluminum sheave w/ bushing
(12) – 3 in. x 12 in. Grey PVC isolators
(6) – Pile mount clamps
(8) – 5/16 in. stainless steel malleable wire rope clips
