4 1/2 in. 4 Ton Swivel Shackle Snatch Block

SKU: 15195 UPC: 602573010204

$129.99

In stock

in stock

Free Shipping
×

Free Shipping

Boat Hoist USA offers free shipping for retail customers on select items. Products eligible for free shipping will be shipped via UPS Ground. We offer expedited services for those individuals that require a more time-sensitive delivery time. If you add any items that are not free shipping, the cart will calculate and display a shipping price based on ONLY the items that are not free shipping. Whenever free shipping is available, it will appear above the "Add to Cart" button on the product page.

Qty.



In Stock

Have questions about this product? Contact us.

4 1/2 in. 4 Ton Swivel Shackle Snatch Block

The block is 4 1/2 inches in size and can handle weights up to 4 tons or 8,000 lbs. It weighs 12.85 lbs. and measures 13 3/4 inches by 4 1/4 inches by 4 1/4 inches. Made of sturdy steel with a black painted finish, it comes with a grease fitting for lubrication, located on the side of the sheave housing, and includes a stainless steel cotter pin and sheave safety pin. The shackle bolt size is 4 1/2 inches by 1/2 inch, with a 2-inch shackle opening, allowing for a 360-degree swivel. Compatible with cables up to 3/8 inch in diameter, note that it won’t fit the BH-USA 12-inch Galvanized Steel Strap Hanger #33850.

4 Ton Swivel Shackle Snatch Block

Product Details

Product Overview
  • Heavy-duty steel construction
  • 4-ton weight rating
  • Swivel shackle for flexibility
  • Greaseable coated sheave
  • Compact and portable design
  • Corrosion-resistant powder-coated finish
  • Secure shackle bolt and safety pin
  • Accepts 3/8" aircraft boat lift cable
  • 360-degree swivel radius
  • Reliable and durable performance
Specifications
Size 4 1/2 in. Weight Rating 4 tons / 8,000 lbs.
Weight 12.85 lbs. Overall Dimensions 13 3/4 in. x 4 1/4 in. x 4 1/4 in.
Material Steel Finish Black
Coating Painted Sheave Size 4 1/2 in.
Sheave Lubrication Press-in grease fitting Grease Fitting Size 1/4 in.
Grease Fitting Location Sheave housing side Cotter Pin Included
Cotter Pin Size 1 in. x 1/8 in. Material Stainless steel
Sheave Safety Pin Included Safety Pin Size 4 1/2 in. x 1/2 in.
Material Stainless steel Shackle Bolt Size 4 1/2 in. x 1/2 in.
Shackle Opening 2 in. Swivel Radius 360 degrees
Cable Compatibility Accepts up to 3/8 in. 7 x 19 aircraft boat lift cable Compatibility Will not fit BH-USA 12" Galvanized Steel Strap Hanger #33850
