4K Aluminum Four Post Top Beam Kit

$ 1,563.13
  • No-weld aluminum design
  • Stainless steel fasteners
  • Fits on 4 dock pilings
  • Includes cable winder, cable, and mounting fasteners
  • 1.5 ID galvanized drive pipe
  • Bronze bearings with 1/4 in. easy-to-reach grease fittings
SKU: 84878
UPC: 091037848789

available

Free Shipping
×

Free Shipping

BH-USA offers free shipping for retail customers on select items. Products eligible for free shipping will be shipped via UPS Ground. We offer expedited services for those individuals that require a more time-sensitive delivery time. If you add any items that are not free shipping, the cart will calculate and display a shipping price based on ONLY the items that are not free shipping. Whenever free shipping is available, it will appear above the "Add to Cart" button on the product page.

Qty.



4K Aluminum Four Post Top Beam Kit

The 4K Aluminum Four Post Top Beam mounts on top of four dock pilings. Made from 6061-T6 US aluminum. The top beam measures 12 ft. 6 in. and the drive pipe measures 11 ft. 11 1/2 in. x 1 1/2 in. inner diameter. The drive pipe is made from schedule 40 galvanized steel. The drive pipe is drilled out for a hoist to fit. Includes all stainless steel mounting fasteners. The bronze bearings have 1/4 in. easy-to-reach grease fittings. Includes one-direction side-mounted (boat lift style) cable winders.

Pile mount brackets, side mount brackets, and hoist mount brackets are not included.

Beam Capacity Used On Post Amount
4K 6K & 8K 4
5K 9K & 10K 4
10K 12K – 20K 4
12K 20K & 24K 6
