Coastal Series Overhead Tritoon Boat Lift
$6,569.67 - $6,929.47
- Durable marine-grade aluminum construction
- No-weld design for easy installation
- Adjustable to fit various boathouse sizes
- Side-mounted drive pipe and boat hoist
- Swaged stainless steel aircraft cable
- Direct-drive motor and gearbox
- 4,000 lbs. and 8,000 lbs. lift capacity options
- Suitable for tritoon-style boats
- Smooth and controlled lifting operation
- Corrosion-resistant materials
- Field-cuttable for customization
- Designed for safety and stability
- Complete, ready-to-install package
- Smooth and efficient lift speed
- Dependable and long-lasting performance
- Suitable for boathouse installations
- Individually crated for shipping
Special Order
Stock Policy
Shipping Policy
Return Policy
Coastal Series Overhead Tritoon Boat Lift
The Coastal Series Overhead Tritoon Boat Lift is offered in two capacities: 4,000 lbs and 8,000 lbs. It includes a top beam made of lightweight aluminum, measuring 12 1/2 ft in length, with a 6-inch web and a 4-inch flange. The drive pipe, which is electro-galvanized, is 13 ft long and has a 2 3/8 inch outer diameter, fitting a 2-inch inner diameter.
For lifting, it uses aircraft cable, with the 4,000 lbs version having a 1/4 inch thick cable that’s 60 ft long, while the 8,000 lbs option has a thicker 5/16 inch cable that’s 100 ft long. The cradle beams, like the top beam, are also made of aluminum and have the same dimensions.
The gearbox, which directly drives the lift, comes in two sizes: one for the 4,000 lbs lift weighing 28.35 lbs and another for the 8,000 lbs lift weighing 38.3 lbs. Both have a gear ratio of 450:1, ensuring smooth operation. They’re permanently lubricated and sealed to prevent any maintenance needs.
The motor options include 1 HP and 1 1/2 HP versions, both with a C-Face mounting type. The 1 HP motor weighs 29 lbs, while the 1 1/2 HP one weighs 39.65 lbs. These motors are powerful enough to lift boats efficiently, with insulation rated as F for safety.
When purchasing the boat lift, it’s essential to have an accessible delivery address for the freight company and a fork truck for unloading. BH-USA ships the lifts in sturdy wood crates and provides 33 ft cable drops for straight-line lifts. They’ll coordinate delivery with the freight company to ensure a smooth process.
