The Max Overhead Boat Sling Lift
$6,255.58 - $8,858.33
- Heavy-duty boat lift
- Professional-grade design
- Long-lasting and durable
- Twin belt-less drives
- 1 1/2 HP stainless steel motors
- Virtually maintenance-free
- Weather-protected steel enclosure
- Tested up to 5,000 lbs.
- Optional bottom plate available
- Quick and simple installation
- Complete with all hardware
- Pre-drilled drive pipes
- Pre-wired motors
- Cradle option available
- Cable and block savers included
- 12,000 lb. lifting capacity
- Made for heavy-duty lifting
- High-volume docking solution
- Engineered by BH-USA
- Shipped in a secure wood crate
Special Order
Stock Policy
Shipping Policy
Return Policy
The Max Overhead Boat Sling Lift
The Max Overhead Boat Sling Lift can handle up to 12,000 lbs and features a strong top beam that’s 14 ft long, 3 1/2 in wide, and 6 in high. The top beam is made of sturdy I-beam material and has a protective galvanized finish. The drive pipe, which is 14 ft long and 2 3/8 in wide, is also galvanized and supported by sealed ball bearings. The lift uses a 2-part cable setup with stainless steel aircraft cable, each section being 50 ft long.
It operates using stainless steel A-Drives, rated at 7,000 lbs each. The gear system is efficient with a double-worm design, and the motor is a powerful 1 1/2 HP stainless steel type. Control is easy with two momentary switches that are GFCI-protected. The lift moves at a speed of 2 ft per minute and comes packaged in a wood crate. If you choose the cradle option, it includes everything needed for setup except for wood bunks. The lift is shipped via freight truck in a large wood crate and requires a fork truck for unloading. It’s important for the buyer to arrange for delivery and unloading, and the freight company can be contacted for assistance.
